Multistage-high pressure centrifugal pump - WK-WKR-WL-WKP

Multistage – High pressure centrifugal pump WK/WKR/WL/WKP

Size: DN 40 ÷ 250

Flow rate: Q up to 1000 m3/h

Pressure head:

  • H up to 400 m (WL/WKP)
  • H up to 350 m (WKR)
  • H up to 150 m (WK)


  • t up to 230 ºC (WK/WL)
  • t -70 ºC/+350 ºC (WKR)

Certificates: ATEX

Maximum pressure: p up to 60 bar

Minimum pressure : p 15 bar (WL)

Speed: n

  • 50 Hz: 2900, 1450 min-1
  • 60 Hz: 3500, 1750 min-1

Maximum speed: n

  • up to 4500 min-1
Certificado Atex
More information

High pressure multistage centrifugal pump, with compensation of axial thrust by bearings or balance drum BB4. Shaft seal with mechanical seal or packing.

Pump construction using those materials most suitable for the fluid to be pumped.

For non-abrasive clean waters or clean fluids, for feeding boilers, pumping condensates, etc.
